Omron 3G3JX

4-86
4-2 Function Mode
4
Functions
Refer to "<Exception Response>" (4-89) if the holding register content reading command has not
been performed normally.
<Writing Into the Coil [05h]>
Writes into one coil.
The coil status change is shown in the following table.
(Example)
•Issues the RUN command to the Inverter with the slave address "8". For running, "03" must be set
to "A002".
•The coil number of the RUN command is "1".
*1. There is no response for broadcasting.
*2. Note that the coil start address is "0", which is smaller by 1 than the coil number "1". The coil
addresses for coil numbers from "1 to 31" are "0 to 30".
Refer to "<Exception Response>" (4-89) if writing into the coil cannot be performed normally.
<Writing into the holding register [06h]>
Writes data into the specified holding register.
(Example)
Write "50 Hz" into the Inverter with slave address "8" as multi-step speed reference 0 (A020).
The data resolution of the holding register "1029h" of multi-step speed reference 0 (A020) is 0.1 Hz.
To set 50 Hz, set the change data to "500 (01F4h)".
Data
Coil status
OFF → ON ON → OFF
Change data (MSB) FFh 00h
Change data (LSB) 00h 00h
Query Response
No. Field name
Example
(Hex)
No. Field name
Example
(Hex)
1 Slave address
*1
08 1 Slave address 08
2 Function code 05 2 Function code 05
3 Coil address
*2
(MSB) 00 3 Coil address
*2
(MSB) 00
4 Coil address
*2
(LSB) 00 4 Coil address
*2
(LSB) 00
5 Change data (MSB) FF 5 Change data (MSB) FF
6 Change data (LSB) 00 6 Change data (LSB) 00
7 CRC-16 (MSB) 8C 7 CRC-16 (MSB) 8C
8 CRC-16 (LSB) A3 8 CRC-16 (LSB) A3
