2-2 Wiring
2
Design
2-2 Wiring
Removing and Mounting the Front Cover
Removing the Front Cover
Loosen the mounting screw at the lower left of the front cover. Lift the bottom of the front cover to
remove while holding the body.
1. Loosen the front cover mounting screw.
2. Lift the bottom of the front cover to remove.
