3-7 Parameter List
3
Operation
3-7 Parameter List
Monitor Mode (d) / Basic Function Mode (F)
Parameter
No.
Name
Monitor or data range
(Digital Operator)
Default
setting
Changes
during
operation
Unit Page
d001
Output frequency
monitor
0.0 to 400.0 ⎯⎯Hz 4-1
d002 Output current monitor 0.0 to 999.9 ⎯⎯A4-1
d003
Rotation direction
monitor
F: Forward
o: Stop
r: Reverse
⎯⎯⎯4-1
d004
PID feedback value
monitor
0.00 to 99.99
100.0 to 999.9
1000. to 9999.
(Enabled when the PID function is selected)
⎯⎯⎯4-1
d005
Multi-function input
monitor
Example)
Terminal
S4, S2: ON
Terminal
S5, S3, S1: OFF
⎯⎯⎯4-2
d006
Multi-function output
monitor
Example)
Terminal P1: ON
Terminal MA: OFF
⎯⎯⎯4-2
d007
Output frequency
monitor
(after conversion)
0.00 to 99.99
100.0 to 999.9
1000. to 9999.
1000 to 3996 (10000 to 39960)
(Output frequency × Conversion factor of
b086)
⎯⎯⎯4-2
d013 Output voltage monitor 0. to 600. ⎯⎯V4-3
d016 Total RUN Time
0. to 9999.
1000 to 9999
⎡100 to ⎡999[h]
⎯⎯h4-3
d017
Power ON time
monitor
0. to 9999.
1000 to 9999
⎡100 to ⎡999[h]
⎯⎯h4-3
d018
Fin temperature
monitor
0.0 to 200.0 °C4-3
d080
Fault frequency
monitor
0. to 9999. ⎯⎯⎯4-3
d081 Fault monitor 1 (Latest)
Error code (condition of occurrence) →
Output frequency [Hz] → Output current [A]
→ Internal DC voltage [V] → RUN time [h] →
ON time [h]
⎯⎯ 4-4d082 Fault monitor 2
d083 Fault monitor 3
d102 DC voltage monitor 0.0 to 999.9 ⎯⎯V4-4
ON
OFF
S5 S4 S3 S2 S1
ON
OFF
MA P1
