Omron 3G3JX

7-17
7-5 Options
7
Specifications
DC Reactor (3G3AX-DL)
Dimensional Drawing
Specifications
Figure 1 Figure 2
Y
Y
D
MAX H
MAX H
D
2-K
MAX B
MAX B
2-K
W
X
Ground terminal (M5)
4-C
X
4-C
Ground terminal (M4)
W
Inverter input
power supply
Model
Figure
No.
Applicable
Inverter
capacity (kw)
Dimensions (mm) Bmax: coil dimensions
Weight
(kg)
Wire size
WDHBXY C K
3/1-phase
200 V AC
3G3AX-
DL2002
Fig. 1
0.2 6690988556725.2 × 8 M4 0.8 1.25 mm
2
min.
3G3AX-
DL2004
0.4 6690989556725.2 × 8 M4 1.0 1.25 mm
2
min.
3G3AX-
DL2007
0.75 66 90 98 105 56 72 5.2 × 8 M4 1.3 2 mm
2
min.
3G3AX-
DL2015
1.5 66 90 98 115 56 72 5.2 × 8 M4 1.6 2 mm
2
min.
3G3AX-
DL2022
2.2 86 100 116 105 71 80 6 × 9 M4 2.1 2 mm
2
min.
3G3AX-
DL2037
3.7 86 100 118 120 71 80 6 × 9 M4 2.6 3.5 mm
2
min.
3G3AX-
DL2055
Fig. 2
5.5 111 100 210 110 95 80 7 × 11 M5 3.6 8 mm
2
min.
3G3AX-
DL2075
7.5 111 100 212 120 95 80 7 × 11 M6 3.9 14 mm
2
min.
