Omron 3G3MX2-A2002-EV2 User Manual

4 Parameter List
4 - 34
Multi-function Compact Inverter 3G3MX2-EV2 User’s Manual (I666-E1)
Parameter
No.
Function name
Monitor or data range
Default
data
Set
data
Changes
during
RUN
Unit
Page
Control
parameters
H109
PM motor
Parameter Ke
0.0001 to 6.5535
Depen-
dent on
capacity
Disabled
Vp/
(rad/s)
P. 6-62
H110
PM motor
Parameter J
0.001 to 9999.000
*1
Depen-
dent on
capacity
Disabled
kgm
2
H111
PM Motor Parameter
R
(Auto-tuning Data)
0.001 to 65.535
Depen-
dent on
capacity
Disabled

P. 6-59
H112
PM Motor Parameter
Ld
(Auto-tuning Data)
0.01 to 655.35
Depen-
dent on
capacity
Disabled
mH
H113
PM motor Parameter
Lq
(Auto-tuning Data)
0.01 to 655.35
Depen-
dent on
capacity
Disabled
mH
H116
PM Motor Speed
Response
1 to 1000
100
Enabled
%
P. 6-64
H117
PM Motor Starting
Current
20.00 to 100.00
70.00
Enabled
%
H118
PM Motor Starting
Time
0.01 to 60.00
1.00
Enabled
s
H119
*2
(Reserved)
0 to 120
100
Enabled
%
H121
PM Motor Minimum
Frequency
0.0 to 25.5
8.0
Enabled
%
H122
PM Motor No-Load
Current
0.00 to 100.00
10.00
Enabled
%
H123
PM Motor Starting
Method Selection
00: Disabled
01: Initial pole position estimation
enabled
00
Disabled
−
H131
PM Motor Initial Pole
Position Estimation 0V
Waiting Times
0 to 255
10
Disabled
time
H132
PM Motor Initial Pole
Position Estimation
Detection Waiting
Times
0 to 255
10
Disabled
time
H133
PM Motor Initial Pole
Position Estimation
Detection Times
0 to 255
30
Disabled
time
H134
PM Initial Pole Posi-
tion Estimation Volt-
age Gain
0 to 200
100
Disabled
%
*1. The digit shift display mode can be used.
*2. Changing it does not affect the operation of the 3G3MX2-EV2 Series Inverter.
