PLC Setup Coding Sheets for Programming Console Appendix E
Value (hex) Origin Compensation Value
A 80000000 −2,147,483,648
to to
00000000 0
to to
7FFFFFFF 2,147,483,647
Value (hex) Origin Search Acceleration Rate
A --- 0001 1 pulse / 4 ms
to to
CJM1 CPU Unit
Ver. 2.0
07D0 2,000 pulses / 4 ms
Pre-Ver. 2.0
CJ1M CPU Unit
FFFF 65,535 pulses / 4 ms
Value (hex) Origin Search Deceleration Rate
A --- 0001 1 pulse / 4 ms
to to
CJM1 CPU Unit
Ver. 2.0
07D0 2,000 pulses / 4 ms
Pre-Ver. 2.0
CJ1M CPU Unit
FFFF 65,535 pulses / 4 ms
Value (hex) Limit Signal Input Type
A0 N.C.
1N.O.
B Origin proximity input signal class (Same as for limit input signal.)
C Origin input signal class (Same as for limit input signal.)
264
@@@@
265
@@@@
A
(Lower)
(Upper)
Address
266@@@@
A
Address
267@@@@
A
Address
268@@@@
A
B
C
Address
