Instruction Execution Times and Number of Steps Section 10-5
10-5-33 Model Conversion Instructions (Unit Ver. 3.0 or Later Only)
Note When a double-length operand is used, add 1 to the value shown in the length
column in the following table.
10-5-34 Special Function Block Instructions (Unit Ver. 3.0 or Later Only)
Note When a double-length operand is used, add 1 to the value shown in the length
column in the following table.
10-5-35 Function Block Instance Execution Time (CPU Units with Unit
Version 3.0 or Later)
Use the following equation to calculate the effect of instance execution on the
cycle time when function block definitions have been created and the
instances copied into the user program using CS/CJ-series CPU Units with
unit version 3.0 or later.
The following table shows the length of time for A, B, and C.
Instruction Mnemonic Code Length
(steps)
(See
note.)
ON execution time (µs) Conditions
CPU6@H-R CPU-6@HCPU-4@HCPU-4@ CJ1M
excluding
CPU11/21
CJ1M
CPU11/21
BLOCK TRANS-
FER
XFERC 565 4 6.4 6.4 6.5 --- 33.1 31.1 Transferring 1 word
481.6 481.6 791.6 --- 3056.1 2821.1 Transferring 1,000
words
SINGLE WORD
DISTRIBUTE
DISTC 566 4 3.4 3.4 3.5 --- 19 18.1 Data distribute
5.9 5.9 7.3 --- 39.5 38.5 Stack operation
DATA COLLECT COLLC 567 4 3.5 3.5 3.85 --- 24.9 29.7 Data collection
8 8 9.1 --- 22.1 25.3 Stack operation
8.3 8.3 9.6 --- 25.5 31 Stack operation
1 word FIFO Read
2052.3 2052.3 2097.5 --- 8310.1 7821.1 Stack operation
1,000 words FIFO
Read
MOVE BIT MOVBC 568 4 4.5 4.5 4.88 --- 28.1 22.1 ---
BIT COUNTER BCNTC 621 4 4.9 4.9 5 --- 30.6 28.8 Counting 1 word
1252.4 1252.4 1284.4 --- 5814.1 5223.8 Counting 1,000
words
Instruction Mnemonic Code Length
(steps)
(See
note.)
ON execution time (
µs) Conditions
CPU6@H-R CPU-6@HCPU-4@HCPU-4@ CJ1M
excluding
CPU11/21
CJ1M
CPU11/21
GET VARIABLE ID GETID 286 4 14 14 22.2 --- 23.4 21.3 ---
Effect of Instance Execution on Cycle Time
= Startup time (A)
+ I/O parameter transfer processing time (B)
+ Execution time of instructions in function block definition (C)
Operation CPU Unit model
CJ1H-
CPU6@H-R
CS1H-
CPU6@H
CJ1H-
CPU6@H
CS1G-
CPU4@H
CJ1G-
CPU4@H
CJ1M-CPU@@
A Startup time Startup time not including
I/O parameter transfer
3.3 µs6.8 µs8.8 µs15.0 µs
