Specifications Section 2-1
2-1 Specifications
2-1-1 Performance Specifications
CJ1-H CPU Units
Note 1. CX-Programmer version 7.1 or higher is required to use the new function-
ality of CJ1-H-R CPU Units.
2. The values displayed in the table are valid when a CPU Unit with unit ver-
sion 4 or later is combined with CX-Programmer 7.0 or higher.
The following table shows the flash memory capacities for CPU Units with unit version 3.
Earlier CPU Units (unit version 2 or earlier) are not equipped with the function that stores data such as
comment files in flash memory.
CPU CJ1H-
CPU67H-R
(See note 1.),
CPU67H
CJ1H-
CPU66H-R
(See note 1.),
CPU66H
CJ1H-
CPU65H-R
(See note 1.),
CPU65H
CJ1H-
CPU64H-R
(See note 1.)
CJ1G-
CPU45H
CJ1G-
CPU44H
CJ1G-
CPU43H
CJ1G-
CPU42H
I/O bits 2,560 1,280 960
User program memory 250 Ksteps 120 Ksteps 60 Ksteps 30 Ksteps 60 Ksteps 30 Ksteps 20 Ksteps 10 Ksteps
Data Memory 32 Kwords
Extended Data Memory 32 Kwords
×
13 banks
E0_00000 to
EC_32767
32 Kwords
×
7 banks
E0_00000 to
E6_32767
32 Kwords
×
3 banks
E0_00000 to
E2_32767
32 Kwords
×
1 bank
E0_00000 to
E0_32767
32 Kwords
× 3
banks
E0_00000 to
E2_32767
32 Kwords
× 1 bank
E0_00000 to E0_32767
Function
blocks
Maximum No.
of definitions
1024 1024 128
Maximum No.
of instances
2048 2048 256
Flash memory
(unit version 4
or later, see
note 2.)
Total (Kbytes)
for FB program
memory, com-
ment files, pro-
gram index
files, and sym-
bol tables
2048 1280 1280 704
Current consumption 0.99 A at 5 V DC 0.91 A at 5 V DC
Connector (provided) One RS-232C Connector (Plug: XM2A-0901, Hood: XM2S-0911-E) provided with CPU Unit as standard
CPU CJ1H-
CPU67H-R,
CPU67H
CJ1H-
CPU66H-R,
CPU66H
CJ1H-
CPU65H-R,
CPU65H
CJ1H-
CPU64H-R
CJ1G-
CPU45H
CJ1G-
CPU44H
CJ1G-
CPU43H
CJ1G-
CPU42H
Flash memory
(unit version 3)
FB program
memory
(Kbytes)
1664 1664 1024 512 1024 512 512 512
Comment files
(Kbytes)
128128646464646464
Program index
files (Kbytes)
128128646464646464
Symbol tables
(Kbytes)
128 128 128 64 128 64 64 64
