Appendix A
Specifications of Basic I/O Units
Basic Input Units
Note Although 16 I/O bits (1 word) are allocated, only 8 of these can be used for external I/O. This Unit is also
treated as a 16-point I/O Unit in the I/O tables.
Basic Mixed I/O Units
Name Specifications Model Number of
input bits
allocated
Page
DC Input Units Terminal block 12 to 24 V DC CJ1W-ID201 8 (16)
(See note.)
539
Terminal block, 24 V DC, 16 inputs CJ1W-ID211 16 540
Fujitsu-compatible connector, CJ1W-ID231 32 542
MIL connector, 24 V DC CJ1W-ID232 32 543
Fujitsu-compatible connector, 24 V DC CJ1W-ID261 64 545
MIL connector, 24 V DC CJ1W-ID262 64 547
AC Input Units Terminal block, 200 to 240 V AC CJ1W-IA201 8 (16)
(See note.)
548
Terminal block, 100 to 120 V AC CJ1W-IA111 16 549
Interrupt Input
Unit
Terminal block, 24 V DC CJ1W-INT01 16 550
Quick-response
Input Unit
Terminal block, 24 V DC CJ1W-IDP01 16 551
Name Specifications Model Number
of bits
allocated
Page
24-V DC
Inputs/
Transis-
tor Out-
put Units
Sinking
output
Fujitsu-compatible connector
Inputs: 24 V DC
Outputs: 12 to 24 V DC, 0.5 A, sinking
CJ1W-MD231 16 input
16 output
553
MIL connector
Inputs: 24 V DC
Outputs: 12 to 24 V DC, 0.5 A, sinking
CJ1W-MD233 555
Fujitsu-compatible connector
Inputs: 24 V DC
Outputs: 12 to 24 V DC, 0.3 A, sinking
CJ1W-MD261 32 input
32 output
559
MIL connector
Inputs: 24 V DC
Outputs: 12 to 24 V DC, 0.3 A, sinking
CJ1W-MD263 561
Sourcing
output
MIL connector
Input: 24 V DC
Outputs: 24 V DC, 0.5 A, load short-circuit
protection
CJ1W-MD232 16 input
16 output
557
TTL I/O Units Inputs: 5 V DC
Outputs: 5 V DC, 35 mA
CJ1W-MD563 32 input
32 output
563
