480
Instruction Execution Times and Number of Steps Section 10-5
Note When a double-length operand is used, add 1 to the value shown in the length
column in the following table.
10-5-10 Conversion Instructions
DOUBLE BCD
SUBTRACT WITH
CARRY
–BCL 417 4 9.4 13.4 14.7 18.8 24.3 27.7 ---
SIGNED BINARY
MULTIPLY
* 420 4 0.26 0.38 0.40 0.58 0.65 0.65 ---
DOUBLE SIGNED
BINARY MULTIPLY
*L 421 4 5.93 7.23 8.45 11.19 13.17 15.0 ---
UNSIGNED
BINARY MULTIPLY
*U 422 4 0.26 0.38 0.40 0.58 0.75 0.75 ---
DOUBLE
UNSIGNED
BINARY MULTIPLY
*UL 423 4 5.9 7.1 8.3 10.63 13.30 15.2 ---
BCD MULTIPLY *B 424 4 8.3 9.0 9.2 12.8 17.5 19.7 ---
DOUBLE BCD
MULTIPLY
*BL 425 4 12.8 23.0 24.2 35.2 36.3 45.7 ---
SIGNED BINARY
DIVIDE
/ 430 4 0.29 0.40 0.42 0.83 0.70 0.70 ---
DOUBLE SIGNED
BINARY DIVIDE
/L 431 4 7.2 7.2 8.4 9.8 13.7 15.5 ---
UNSIGNED
BINARY DIVIDE
/U 432 4 0.29 0.40 0.42 0.83 0.8 0.8 ---
DOUBLE
UNSIGNED
BINARY DIVIDE
/UL 433 4 6.9 6.9 8.1 9.1 12.8 14.7 ---
BCD DIVIDE /B 434 4 8.6 8.6 8.8 15.9 19.3 22.8 ---
DOUBLE BCD
DIVIDE
/BL 435 4 13.1 17.7 18.9 26.2 27.1 34.7 ---
Instruction Mnemonic Code Length
(steps)
(See
note 1.)
ON execution time (
µs) Conditions
CPU6@H-R CPU6@HCPU4@HCPU4@ CJ1M
excluding
CPU11/21
CJ1M
CPU11/21
BCD-TO-BINARY BIN 023 3 0.18 0.22 0.24 0.29 0.40 0.40 ---
DOUBLE BCD-TO-
DOUBLE BINARY
BINL 058 3 6.1 6.5 6.8 9.1 12.3 13.7 ---
BINARY-TO-BCD BCD 024 3 0.19 0.24 0.26 8.3 7.62 9.78 ---
DOUBLE BINARY-
TO-DOUBLE BCD
BCDL 059 3 6.7 6.7 7.0 9.2 10.6 12.8 ---
2’S COMPLE-
MENT
NEG1603 0.14 0.180.200.290.350.35---
DOUBLE 2’S
COMPLEMENT
NEGL 161 3 0.26 0.32 0.34 0.5 0.60 0.60 ---
16-BIT TO 32-BIT
SIGNED BINARY
SIGN 600 3 0.26 0.32 0.34 0.50 0.60 0.60 ---
DATA DECODER MLPX 076 4 0.32 0.32 0.42 8.8 0.85 0.85 Decoding 1 digit
(4 to 16)
0.98 0.98 1.20 12.8 1.60 1.60 Decoding 4 digits
(4 to 16)
3.30 3.30 4.00 20.3 4.70 4.70 Decoding 1 digit
(8 to 256)
6.50 6.50 7.90 33.4 8.70 8.70 Decoding 4 digits
(8 to 256)
DATA ENCODER DMPX 077 4 7.5 7.5 7.9 10.4 9.4 13.9 Encoding 1 digit
(16 to 4)
49.6 49.6 50.2 59.1 57.3 71.73 Encoding 4 digits
(16 to 4)
18.2 18.2 18.6 23.6 56.8 82.7 Encoding 1 digit
(256 to 8)
55.1 55.1 57.4 92.5 100.0 150.7 Encoding 2 digits
(256 to 8)
Instruction Mnemonic Code Length
(steps)
(See
note.)
ON execution time (
µs) Conditions
CPU6@H-R CPU6@HCPU4@HCPU4@ CJ1M
excluding
CPU11/21
CJ1M
CPU11/21
