122
C-mode Command Details Section 4-3
End Codes An end code of 14 (format error) will be returned if the length of the command
is incorrect.
An end code of 15 (entry number data error) will be returned if the timer/
counter type or timer/counter number is out of range (including hexadecimal
data).
An end code of 16 (command not supported) will be returned if the specified
instruction does not exist in the UM Area.
4-3-18 TIMER/COUNTER SV READ 2 – – R$
From the specified program address onwards in cyclic task 0, TIMER/
COUNTER SV READ 2 finds the specified timer/counter instruction and reads
the 4-digit constant SV that is set or the word address where the SV is stored.
Command Format
Note “SP” represents a space (20 Hex).
End code (Hex) Contents
00 Normal completion
13 FCS error
14 Format error
15 Entry number data error
16 Command not supported
18 Frame length error
21 Not executable due to CPU Unit CPU error.
23 User memory protected
Instruction name Timer/counter type Timer/counter
number (BCD)
Char-
acter 1
Char-
acter 2
Char-
acter 3
Char-
acter 4
HIGH-SPEED COUNTER
WAIT
T M H W 0000 to 2047
TIMER WAIT T I M W
COUNTER WAIT C N T W
HIGH-SPEED TIMER T I M H
TOTALIZING TIMER TTI M
REVERSIBLE COUNTER C N T R
TIMER T I M (SP)
COUNTER C N T (SP)
x 10
0
x 10
0
@R$
x 10
0
x 10
1
x 10
3
x 10
2
x 10
1
OP1 OP2 OP3 OP4
x 10
3
x 10
2
x 10
1
* ↵
Unit No. (BCD) Program address
(BCD)
Timer/counter type
Timer/counter
number (BCD)
TerminatorFCSHeader
code
