Omron CPM1 Programming Manual

143
CPM1/CPM1A Memory Area Functions Section 3-2
3-2-2 IR Area
The functions of the IR area are explained below.
I/O Bits IR area bits from IR 00000 to IR 01915 are allocated to terminals on the CPU
Unit and I/O Units. They reflect the ON/OFF status of input and output signals.
Input bits begin at IR 00000, and output bits begin at IR 01000.
The following table shows which IR bits are allocated to the I/O terminals on
the CPM1 CPU Units and CPM1-20EDR I/O Unit.
The following table shows which IR bits are allocated to the I/O terminals on
the CPM1A’s CPU Units and Expansion I/O Unit.
Work Bits The work bits can be used freely within the program. They can only be used
within the program, however, and not for direct external I/O.
CPM1 CPU Unit I/O CPU Unit Terminals I/O Unit Terminals
CPM1-10CDR-@ Inputs 6 points: 00000 to 00005 12 points: 00100 to 00111
Outputs 4 points: 01000 to 01003 8 points: 01100 to 01107
CPM1-20CDR-@ Inputs 12 points: 00000 to 00011 12 points: 00100 to 00111
Outputs 8 points: 01000 to 01007 8 points: 01100 to 01107
CPM1-30CDR-@ Inputs 18 points:
00000 to 00011,
00100 to 00105
12 points: 00200 to 00211
Outputs 12 points:
01000 to 01007,
01100 to 01103
8 points: 01200 to 01207
CPM1-30CDR-@-
V1
Inputs 18 points:
00000 to 00011,
00100 to 00105
36 points:00200 to 00211
00300 to 00311
00400 to 00411
Outputs 12 points:
01000 to 01007,
01100 to 01103
24 points:01200 to 01207
01300 to 01407
01400 to 01407
Number
of I/O
terminals
on the
CPU Unit
CPU Unit terminals CPM1A-20ED@ Expansion I/O Unit Terminals Power
supply
Model
number
Inputs Outputs Inputs Outputs Inputs Outputs Inputs Outputs
10 6 points:
00000 to
00005
4 points:
01000 to
01003
--- --- --- --- --- --- AC CPM1A-
10CD@-A
DC CPM1A-
10CD@-D
20 12 points:
00000 to
00011
8 points:
01000 to
01007
--- --- --- --- --- --- AC CPM1A-
20CD@-A
DC CPM1A-
20CD@-D
30 18 points:
00000 to
00011
00100 to
00105
12 points:
01000 to
01007
01100 to
01103
12 points:
00200 to
00211
8 points:
01200 to
01207
12 points:
00300 to
00311
8 points:
01300 to
01307
12 points:
00400 to
00411
8 points:
01400 to
01407
AC CPM1A-
30CD@-A
DC CPM1A-
30CD@-D
40 24 points:
00000 to
00011
00100 to
00111
16 points:
01000 to
01007
01100 to
01107
12 points:
00200 to
00211
8 points:
01200 to
01207
12 points:
00300 to
00311
8 points:
01300 to
01307
12 points:
00400 to
00411
8 points:
01400 to
01407
AC CPM1A-
40CD@-A
DC CPM1A-
40CD@-D

Omron CPM1 Specifications

General

Model	CPM1
Manufacturer	Omron
Instruction Set	Basic and advanced instructions
Power Supply	100 to 240 VAC or 24 VDC
Communication	RS-232C
I/O Points	10, 20, 30, or 40 points depending on the model
Timers	Yes, multiple timers available
Counters	Yes, multiple counters available
Input Voltage	24V DC
Output Type	Relay or transistor
Number of I/O Points	10, 20, 30, 40
Communication Ports	RS-232C (optional)
Operating Temperature	0°C to 55°C
Storage Temperature	-20°C
Humidity	10% to 90% (non-condensing)
Dimensions	Varies depending on the model
Weight	Varies depending on the model
Program Memory	2048 steps (2K steps)
