Omron CPM1 Programming Manual

260
Conversion Instructions Section 5-19
Flags ER: Indirectly addressed DM word is non-existent. (Content of *DM word
is not BCD, or the DM area boundary has been exceeded.)
EQ: ON when the result is zero.
5-19-3 DOUBLE BCD-TO-DOUBLE BINARY – BINL(58)
Limitations This instruction is available in the CQM1 only.
DM 6143 to DM 6655 cannot be used for R.
Description When the execution condition is OFF, BINL(58) is not executed. When the
execution condition is ON, BINL(58) converts an eight-digit number in S and
S+1 into 32-bit binary data, and outputs the converted data to R and R+1.
Flags ER: The contents of S and/or S+1 words are not BCD.
Indirectly addressed DM word is non-existent. (Content of *DM word
is not BCD, or the DM area boundary has been exceeded.)
EQ: ON when the result is zero.
5-19-4 DOUBLE BINARY-TO-DOUBLE BCD – BCDL(59)
Limitations This instruction is available in the CQM1 only.
If the content of S exceeds 05F5E0FF, the converted result would exceed
99999999 and BCDL(59) will not be executed. When the instruction is not
executed, the content of R and R+1 remain unchanged.
DM 6143 to DM 6655 cannot be used for R.
S: First source word (BCD)
IR, SR, AR, DM, HR, TC, LR
R: First result word
IR, SR, AR, DM, HR, LR
Ladder Symbols Operand Data Areas
BINL(58)
S
R
@BINL(58)
S
R
S + 1 S
R + 1 R
BCD
Binary
S: First source word (binary)
IR, SR, AR, DM, HR, LR
R: First result word
IR, SR, AR, DM, HR, LR
Ladder Symbols Operand Data Areas
BCDL(59)
S
R
@BCDL(59)
S
R
