Omron CPM1 Programming Manual

198
Instruction Tables Section 5-6
DVB (@) 53 4 BINARY DIVIDE All 299
END 01 1 END All 205
FAL (@) 06 2 FAILURE ALARM AND RESET All 209
FALS 07 2 SEVERE FAILURE ALARM All 209
FCS (@) –– 4 FCS CALCULATE CQM1/SRM1 only 328
FPD –– 4 FAILURE POINT DETECT CQM1 only 330
HEX (@) –– 4 ASCII-TO-HEXADECIMAL CQM1/SRM1 only 269
HKY –– 4 HEXADECIMAL KEY INPUT CQM1 only 355
HMS –– 4 SECONDS TO HOURS CQM1 only 279
IL 02 1 INTERLOCK All 205
ILC 03 1 INTERLOCK CLEAR All 205
INC (@) 38 2 INCREMENT All 319
INI (@) 61 4 MODE CONTROL All 225
INT (@) 89 4 INTERRUPT CONTROL All 334
IORF (@) 97 3 I/O REFRESH All 326
JME 05 2 JUMP END All 207
JMP 04 2 JUMP All 207
KEEP 11 2 KEEP All 203
LD None 1 LOAD All 200
LD NOT None 1 LOAD NOT All 200
LINE –– 4 LINE CQM1 only 280
MAX (@) –– 4 FIND MAXIMUM CQM1 only 307
MBS (@) –– 4 SIGNED BINARY MULTIPLY CQM1-CPU4@-E/-EV1 only 303
MBSL (@) –– 4 DOUBLE SIGNED BINARY MULTIPLY CQM1-CPU4@-E/-EV1 only 304
MCMP (@) 19 4 MULTI-WORD COMPARE CQM1 only 308
MCRO (@) 99 4 MACRO All 327
MIN (@) – – 4 FIND MINIMUM CQM1 only 308
MLB (@) 52 4 BINARY MULTIPLY All 299
MLPX (@) 76 4 4-TO-16 DECODER All 261
MOV (@) 21 3 MOVE All 237
MOVB (@) 82 4 MOVE BIT All 245
MOVD (@) 83 4 MOVE DIGIT All 246
MSG (@) 46 2 MESSAGE All 325
MUL (@) 32 4 BCD MULTIPLY All 288
MULL (@) 56 4 DOUBLE BCD MULTIPLY All 294
MVN (@) 22 3 MOVE NOT All 238
NEG (@) –– 4 2’S COMPLEMENT CQM1-CPU4@-E/-EV1 only 282
NEGL (@) –– 4 DOUBLE 2’S COMPLEMENT CQM1-CPU4@-E/-EV1 only 283
NOP 00 1 NO OPERATION All 205
OR None 1 OR All 200
OR LD None 1 OR LOAD All 201
OR NOT None 1 OR NOT All 200
ORW (@) 35 4 LOGICAL OR All 317
OUT None 2 OUTPUT All 201
OUT NOT None 2 OUTPUT NOT All 201
PID –– 4 PID CONTROL CQM1-CPU4@-E/-EV1 only 347
PLS2 (@) –– 4 PULSE OUTPUT CQM1-CPU43-E/-EV1 only 340
PRV (@) 62 4 HIGH-SPEED COUNTER PV READ All 227
Mnemonic Code Words Name CPU Units Page

Omron CPM1 Specifications

General

Model	CPM1
Manufacturer	Omron
Instruction Set	Basic and advanced instructions
Power Supply	100 to 240 VAC or 24 VDC
Communication	RS-232C
I/O Points	10, 20, 30, or 40 points depending on the model
Timers	Yes, multiple timers available
Counters	Yes, multiple counters available
Input Voltage	24V DC
Output Type	Relay or transistor
Number of I/O Points	10, 20, 30, 40
Communication Ports	RS-232C (optional)
Operating Temperature	0°C to 55°C
Storage Temperature	-20°C
Humidity	10% to 90% (non-condensing)
Dimensions	Varies depending on the model
Weight	Varies depending on the model
Program Memory	2048 steps (2K steps)
