Omron CPM1 Programming Manual

197
Instruction Tables Section 5-6
5-6-4 Alphabetic List by Mnemonic
Dashes (“–”) in the Code column indicate expansion instructions, which do not
have fixed function codes. “None” indicates instructions for which function
codes are not used.
Mnemonic Code Words Name CPU Units Page
7SEG 88 4 7-SEGMENT DISPLAY OUTPUT CQM1 only 354
ACC (@) –– 4 ACCELERATION CONTROL CQM-CPU43-E/-EV1 only 342
ADB (@) 50 4 BINARY ADD All 296
ADBL (@) –– 4 DOUBLE BINARY ADD CQM1-CPU4@-E/-EV1 only 300
ADD (@) 30 4 BCD ADD All 285
ADDL (@) 54 4 DOUBLE BCD ADD All 291
AND None 1 AND All 200
AND LD None 1 AND LOAD All 201
AND NOT None 1 AND NOT All 200
ANDW (@) 34 4 LOGICAL AND All 316
APR (@) –– 4 ARITHMETIC PROCESS CQM1 only 313
ASC (@) 86 4 ASCII CONVERT All 268
ASFT(@) 17 4 ASYNCHRONOUS SHIFT REGISTER All 235
ASL (@) 25 2 ARITHMETIC SHIFT LEFT All 230
ASR (@) 26 2 ARITHMETIC SHIFT RIGHT All 231
AVG –– 4 AVERAGE VALUE CQM1 only 309
BCD (@) 24 3 BINARY TO BCD All 259
BCDL (@) 59 3 DOUBLE BINARY-TO-DOUBLE BCD CQM1 only 260
BCMP (@) 68 4 BLOCK COMPARE All 250
BCNT (@) 67 4 BIT COUNTER All 328
BIN (@) 23 3 BCD-TO-BINARY All 258
BINL (@) 58 3 DOUBLE BCD-TO-DOUBLE BINARY CQM1 only 260
BSET (@) 71 4 BLOCK SET All 239
CLC (@) 41 1 CLEAR CARRY All 285
CMP 20 3 COMPARE All 248
CMPL 60 4 DOUBLE COMPARE All 252
CNT None 2 COUNTER All 214
CNTR 12 3 REVERSIBLE COUNTER All 216
COLL (@) 81 4 DATA COLLECT All 242
COLM(@) –– 4 LINE TO COLUMN CQM1 only 281
COM (@) 29 2 COMPLEMENT All 316
CPS –– 4 SIGNED BINARY COMPARE CQM1-CPU4@-E/-EV1 only 254
CPSL –– 4 DOUBLE SIGNED BINARY COMPARE CQM1-CPU4@-E/-EV1 only 255
CTBL(@) 63 4 COMPARISON TABLE LOAD All 220
DBS (@) –– 4 SIGNED BINARY DIVIDE CQM1-CPU4@-E/-EV1 only 305
DBSL (@) –– 4 DOUBLE SIGNED BINARY DIVIDE CQM1-CPU4@-E/-EV1 only 306
DEC (@) 39 2 BCD DECREMENT All 319
DIFD 14 2 DIFFERENTIATE DOWN All 204
DIFU 13 2 DIFFERENTIATE UP All 204
DIST (@) 80 4 SINGLE WORD DISTRIBUTE All 241
DIV (@) 33 4 BCD DIVIDE All 289
DIVL (@) 57 4 DOUBLE BCD DIVIDE All 294
DMPX (@) 77 4 16-TO-4 ENCODER All 263
DSW 87 4 DIGITAL SWITCH CQM1 only 355

Omron CPM1 Specifications

General

Model	CPM1
Manufacturer	Omron
Instruction Set	Basic and advanced instructions
Power Supply	100 to 240 VAC or 24 VDC
Communication	RS-232C
I/O Points	10, 20, 30, or 40 points depending on the model
Timers	Yes, multiple timers available
Counters	Yes, multiple counters available
Input Voltage	24V DC
Output Type	Relay or transistor
Number of I/O Points	10, 20, 30, 40
Communication Ports	RS-232C (optional)
Operating Temperature	0°C to 55°C
Storage Temperature	-20°C
Humidity	10% to 90% (non-condensing)
Dimensions	Varies depending on the model
Weight	Varies depending on the model
Program Memory	2048 steps (2K steps)
