Omron CPM1 Programming Manual

146
SRM1 Memory Area Functions Section 3-3
Note 1. IR and LR bits that are not used for their allocated functions can be used
as work bits.
2. The contents of the HR area, LR area, Counter area, and read/write DM
area are backed up by a capacitor. At 25
°C, the capacitor will back up
memory for 20 days. Refer to 2-1-2 Characteristics in the SRM1 Master
Control Unit Operation Manual for a graph showing the backup time vs.
temperature.
3. When accessing a PV, TC numbers are used as word data; when access-
ing Completion Flags, they are used as bit data.
4. Data in DM 6144 to DM 6655 cannot be overwritten from the program, but
they can be changed from a Peripheral Device.
3-3-2 IR Area
The functions of the IR area are explained below.
I/O Bits IR area bits from IR 00000 to IR 01915 are allocated to terminals on the CPU
Unit and I/O Unit. They reflect the ON/OFF status of input and output signals.
Input bits begin at IR 00000, and output bits begin at IR 01000.
Refer to 1-4 I/O and Data Area Allocation in the SRM1 Master Control Units
Operation Manual for further details.
Work Bits The work bits can be used freely within the program. They can only be used
within the program, however, and not for direct external I/O.
Timer/Counter area
2
TC 000 to TC 127 (timer/counter numbers)
3
Timers and counter use the TIM, TIMH(15),
CNT and CNTR(12) instructions. The same
numbers are used for both timers and
counters.
Timer/counter numbers should be specified
as bits when dealing with timer/counter
present values. The counter data will be
stored even when the SRM1 power is turned
off or operation is stopped or started.
When timer/counter are treated as up-flags
the number should be specified as relay
data.
DM area
Read/write
2
DM 0000 to DM 1999
(2,000 words)
--- DM area data can be accessed in word units
only. Word values are retained when the
power is turned off, or operation started or
stopped.
Read/write areas can be read and written
freely within the program.
Error log
4
DM 2000 to DM 2021
(22 words)
--- Used to store the time of occurrence and
error code of errors that occur. Refer to 5-5
Coding Right-hand Instructions.
Read-only
4
DM 6144 to DM 6599
(456 words)
--- Cannot be overwritten from program.
PC Setup
4
DM 6600 to DM 6655
(56 words)
--- Used to store various parameters that con-
trol PC operation.
Data area Words Bits Function

Omron CPM1 Specifications

General

Model	CPM1
Manufacturer	Omron
Instruction Set	Basic and advanced instructions
Power Supply	100 to 240 VAC or 24 VDC
Communication	RS-232C
I/O Points	10, 20, 30, or 40 points depending on the model
Timers	Yes, multiple timers available
Counters	Yes, multiple counters available
Input Voltage	24V DC
Output Type	Relay or transistor
Number of I/O Points	10, 20, 30, 40
Communication Ports	RS-232C (optional)
Operating Temperature	0°C to 55°C
Storage Temperature	-20°C
Humidity	10% to 90% (non-condensing)
Dimensions	Varies depending on the model
Weight	Varies depending on the model
Program Memory	2048 steps (2K steps)
