Omron CPM1 Programming Manual

76
CPM1/CPM1A Interrupt Functions Section 1-6
and decrementing will begin again after the subroutine has been called. In
the scheduled interrupt mode, interrupts will continue to be repeated at
fixed intervals until the operation is stopped.
2. When C
2
is entered as a constant:
The settings are the same as for the one-shot mode, but interrupts will con-
tinue to be repeated at fixed intervals until the operation is stopped.
Reading the Timer’s Elapsed Time
Use the STIM(69) instruction to read the timer’s elapsed time.
C
2
: Number of times the decrementing counter has ben decremented (4 digits
BCD)
C
2
+ 1: Decrementing counter time interval (4 digits BCD; unit: 0.1 ms)
C
3
: Elapsed time from previous decrement (4 digits BCD; unit: 0.1 ms)
The time from when the interval timer is started until the execution of this
instruction is calculated as follows:
{(Content of C2)
× (Content of C2+1) + (Content of C3)} × 0.1 ms
If the specified interval timer is stopped, then “0000” will be stored.
Stopping the Timer
Use the STIM(69) instruction to stop the interval timer. The interval timer will
be stopped.
(@)STIM(69)
C
1
C
2
C
3
C
1
: Read elapsed time (006)
C
2
: Leading word of parameter 1
C
3
: Parameter 2
(@)STIM(69)
C
1
000
000
C
1
: Stop interval timer (010)

Omron CPM1 Specifications

General

Model	CPM1
Manufacturer	Omron
Instruction Set	Basic and advanced instructions
Power Supply	100 to 240 VAC or 24 VDC
Communication	RS-232C
I/O Points	10, 20, 30, or 40 points depending on the model
Timers	Yes, multiple timers available
Counters	Yes, multiple counters available
Input Voltage	24V DC
Output Type	Relay or transistor
Number of I/O Points	10, 20, 30, 40
Communication Ports	RS-232C (optional)
Operating Temperature	0°C to 55°C
Storage Temperature	-20°C
Humidity	10% to 90% (non-condensing)
Dimensions	Varies depending on the model
Weight	Varies depending on the model
Program Memory	2048 steps (2K steps)
