Omron F3SG-SR Series User Manual

F3SG-SR/PG
43
Ordering Information
Reduced Wiring System
Y-Joint Plug/Socket Connector
*1. When the accessory is used, protect it from cutting oil.
*2. Order the cable (root-plug cable for extended and extended cable) for emitter (end of model: -L) and the cable for receiver (end of model: -D).
Reset Switch Connector
Note: The customer needs to prepare a reset switch (NC contact).
*1. When the accessory is used, protect it from cutting oil.
*2. Order the extended socket-straight cable for receiver (end of model: -D).
Reset Switch Connector-to-Reset Switch Cable
Connector Connected to Cable, Socket on One Cable End
* When the accessory is used, protect it from cutting oil.
Appearance Type Cable length Specifications Model
M12 connectors.
Used for reduced wiring.
IP67*1 rated when mated.
0.5 m F39-GCNY2
Appearance Type Cable length Specifications Model
M12 connectors.
Used for reduced wiring.
IP67*1 rated when mated.
0.5 m F39-GCNY3
Appearance Type Cable length Specifications Model
M12 connector (4-pin), 4
wires
1 m XS5F-D421-C80-F
2 m XS5F-D421-D80-F
3 m XS5F-D421-E80-F
5 m XS5F-D421-G80-F
10 m XS5F-D421-J80-F
20 m XS5F-D421-L80-F
Emitter
Extended
Plug-Socket Cable
F39-JG
@
B-L (Gray)
*
2
Root-Plug Cable for
Extended
F39-JGR3K-L (Gray)
*
2
Extended
Socket-Straight Cable
F39-JG
@
A-D (Black)
*
2
Root-Plug Cable for
Extended
F39-JGR3K-D (Black)
*
2
Y-Joint Plug/
Socket Connector for
Advanced type
F39-GCNY2
Receiver
F3SG-SR/PG
XS5F-D421
@
80-F
Extended
Socket-Straight Cable
F39-JG
@
A-D (Black)
*
2
Reset Switch
Connector
F39-GCNY3
Root-Plug Cable for
Extended
F39-JGR3K-D (Black)
*
2
F3SG-SR/PG
Receiver or emitter/receiver
Connect to
a reset switch (NC contact)
Brown
White
Blue
Black
24V/0V
RESET
0V/24V
AUX
1
2
3
4
Female
IP67* rated when mated.
3
21
4
