Parameter
No.
Function name Monitor or Data Range
Default
data
Setting
during
RUN
Unit Page
A33
2nd Magnetic Satura-
tion Factor 4
0.0 to 300.0 %
58.3
Availa-
ble
%
page
6-65
A34
2nd Magnetic Satura-
tion Factor 5
0.0 to 300.0 %
46.1
Availa-
ble
%
page
6-65
A40
2nd Slip Compensa-
tion Operating Condi-
tions Selection
0: Enable during acceleration/
deceleration, enable at base
frequency or higher
1: Disable during acceleration/
deceleration, enable at base
frequency or higher
2: Enable during acceleration/
deceleration, disable at base
frequency or higher
3: Disable during acceleration/
deceleration, disable at base
frequency or higher
0 - -
page
5-16
A41
2nd Output Current
Fluctuation Damping
Gain
0.00 to 1.00
0.20
Availa-
ble
-
page
7-144
A43
Speed Control 2
Speed Command Fil-
ter
0.000 to 5.000 s
0.02
Availa-
ble
s
page
6-26
A44
Speed Control 2
Speed Detection Filter
0.000 to 0.100 s
0.005
Availa-
ble
s
page
6-26
A45
Speed Control 2 P
Proportional Gain
0.1 to 200.0
10
Availa-
ble
-
page
6-26
A46
Speed Control 2 I Inte-
gral Time
0.001 to 9.999 s
999: Cancel integral term
0.1
Availa-
ble
s
page
6-26
A47
Speed Control 2 FF
Gain
0.00 to 99.99 s
0
Availa-
ble
s
page
6-26
4 Parameter List
4-139
M1 Series Standard Type User's Manual (I669)
4-2 List of Parameters by Group
4
4-2-6 Parameter A (Motor 2 Parameter)

Omron M1 Series Specifications

General

Input Voltage	200-240V AC
Output Voltage	3-phase 200 to 240 VAC
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overheating, Short Circuit
Communication	RS-485, Modbus RTU
Enclosure	IP20
Cooling Method	Fan Cooled
Operating Temperature	-10°C to +50°C
Humidity	5-95% (non-condensing)
Altitude	Up to 1000m
Frequency Range	0.5-400 Hz
Storage Temperature	-20°C to +65°C
