9 - 53
9 Setting Up Slave Terminals
NX-series EtherNet/IP Coupler Unit User’s Manual (W536)
9-5 Setting Tag Data Links
9
9-5-5 Creating Tags and Tag Sets
3 Click the Import button on the Tag Sets Tab Page of the Edit Device Parameter Dialog Box.
A confirmation dialog box is displayed that asks you how you want to import the variables as
shown below.
To import all symbols with a Network Publish attribute, click the Yes button. To import only some
of these variables, click the No button.
After you import the variables to the tags, click the Yes button to automatically create tag sets,
or click the No button to set up tag sets manually.
The symbols will be imported as shown below on the Tag Sets Tab Page. Each symbol will be
imported into a different tag set and the device parameters will be automatically edited. (The
symbol name will be used for the tag set name.)
