Appendices
A - 64
NX-series EtherNet/IP Coupler Unit User’s Manual (W536)
This section lists other objects.
• Subindex 04 tells whether the serial number verification is enabled.
0: Not checked.
1: Checked.
Serial numbers are verified only for NX Units (not for EtherNet/IP Coupler Units).
• Subindex 02 hex gives the wait time to monitor for connection of the NX Units.
• Subindex 01 hex specifies whether to use fail-soft operation for the EtherNet/IP Slave Terminal.
Set subindex 01 to Fail-soft operation to use fail-soft operation.
0: Fail-soft operation
1: Stop
Refer to 11-7 Fail-soft Operation on page 11-26 for details on fail-soft operation.
A-8-5 Other Objects
Index
(hex)
Subin-
dex
(hex)
Object name Default Data range Unit Data type
Acc
ess
I/O
allo-
cat-
ion
Data
attri-
bute
4000 --- NX Unit Configuration --- --- --- --- --- --- ---
00 Number of Entries 4 4 --- USINT RO Not
pos-
sible.
---
04 NX Unit Serial Number
Verification Setting
0 0 or 1 --- USINT RW Not
pos-
sible.
Y
Index
(hex)
Subin-
dex
(hex)
Object name Default Data range Unit Data type
Acc
ess
I/O
allo-
cat-
ion
Data
attri-
bute
4007 --- Error Detection Setting
of NX Unit
--- --- --- --- --- --- ---
00 Number of Entries 2 2 --- USINT RO Not
pos-
sible.
---
02 NX Unit Connection Wait
Time
3 3 to 200 s UINT RW Not
pos-
sible.
Y
Index
(hex)
Subin-
dex
(hex)
Object name Default Data range Unit Data type
Acc
ess
I/O
allo-
cat-
ion
Data
attri-
bute
400D --- Fail-soft Operation Set-
ting
--- --- --- --- --- --- ---
00 Number of Entries 1 1 --- USINT RO Not
pos-
sible.
---
01 Fail-soft Operation Set-
ting
1 0 or 1 --- USINT RW Not
pos-
sible.
Y
