Omron NX-EIC202 User Manual

Appendices
A - 56
NX-series EtherNet/IP Coupler Unit User’s Manual (W536)
A-7 Dimensions
 EtherNet/IP Coupler Unit Only
*1. The dimension is 1.35 mm for Units with lot numbers through December 2014.
 With Cables Connected
*1. This dimension depends on the specifications of the commercially available USB certified cable. Check
the specifications of the USB cable that is used.
A-7-1 EtherNet/IP Coupler Unit
80
71
65.2
104.5
100
48.1
46
1.5
1.5
0
1
2
3
4
5
6
7
8
9
A
B
C
D
E
F
0
1
2
3
4
5
6
7
8
9
A
B
C
D
E
F
NX-EIC202
NET
0.55
*1
Unit: mm
100 to 120
*2
USB cable
Communications cable
*1
71
5.8
Unit: mm
