1 EtherNet/IP Networks
NX-series EtherNet/IP Coupler Unit User’s Manual (W536)
1-2 EtherNet/IP Network Config-
uration Elements
1
1-2-1 System Configuration Example of an EtherNet/IP Network
1-2 EtherNet/IP Network Configuration
Elements
This section describes the devices that configure EtherNet/IP networks and the usage of those devices.
This section provides a system configuration example of an EtherNet/IP network.
1-2-1 System Configuration Example of an EtherNet/IP Network
Item
Number
Item
1 Support Software
2EDS File
3 Ethernet Switch
4 EtherNet/IP master
5 NX Unit Power Supply
6 NX I/O Power Supply
7 EtherNet/IP Coupler Unit
8 NX Units
9 Communication Cables
10 EtherNet/IP slaves
5
6
10
5
Switch
6
1
2
3
4
8
8
8
9
9
9
7
7 7
9
.EDS
