Omron NX-EIC202 User Manual

9 - 3
9 Setting Up Slave Terminals
NX-series EtherNet/IP Coupler Unit User’s Manual (W536)
9-1 Settings and Setting Proce-
dures
9
9-1-1 Items to Set
9-1 Settings and Setting Procedures
As examples, this section describes EtherNet/IP Slave Terminal setting items and procedure and the
settings that are required to access I/O data in EtherNet/IP Slave Terminals from a CJ-series Ether-
Net/IP Unit. For other settings and setting procedures, refer to the operation manual for the Support
Software that you will use.
Additional Information
• Refer to A-2 TCP/UDP Message Service on page A-34 for details on the TCP/UDP message
service.
• If you do not use a Safety Control Unit, you do not need any Support Software to use the Eth-
erNet/IP Slave Terminal with the default settings. Refer to A-5 Application Procedure for the
Default Settings on page A-52 for information on using an EtherNet/IP Slave Terminal with
the default settings.
The settings that are used to access I/O data in the Slave Terminals from a CJ EtherNet/IP Unit can be
divided into two areas:
• NX-I/O Units data
• EtherNet/IP data
This data is set using Support Software.
This data is set using a configuration tool such as the OMRON Network Configurator.
9-1-1 Items to Set
NX-I/O Units Data
Setting Description
Setting Slave Terminal Config-
uration and Operation Settings
Adjust the settings of the Slave Terminal with the configuration and operation
settings of the NX Units and EtherNet/IP Coupler Unit using Support Software.
EtherNet/IP Data
Setting Description
Setting IP Address Set the IP address of the EtherNet/IP Coupler Unit.
Setting the Clock Time Set the clock of the EtherNet/IP Coupler Unit.
Setting Tag Data Links Set the tag data links for the EtherNet/IP Unit.
Assigning Network Variables Assign and register the network variables that are required to access the I/O
data from the user program.
