3 Specifications and Application Procedures
3 - 2
NX-series EtherNet/IP Coupler Unit User’s Manual (W536)
3-1 Specifications
This section provides the general specifications of an EtherNet/IP Slave Terminal and the specifications
of the EtherNet/IP Coupler Unit and End Cover.
3-1-1 General Specifications of EtherNet/IP Slave Terminals
Item Specification
Enclosure Mounted in a panel
Grounding method Ground to 100 Ω or less.
Operat-
ing envi-
ronment
Ambient operating
temperature
0 to 55°C
Ambient operating
humidity
10% to 95% (with no condensation or icing)
Atmosphere Must be free from corrosive gases.
Ambient storage
temperature
−25 to 70°C (with no condensation or icing)
Altitude 2,000 m max.
Pollution degree 2 or less: Conforms to JIS B3502 and IEC 61131-2.
Noise immunity 2 kV on power supply line (Conforms to IEC61000-4-4.)
Overvoltage cate-
gory
Category II: Conforms to JIS B3502 and IEC 61131-2.
EMC immunity
level
Zone B
Vibration resis-
tance
Conforms to IEC 60068-2-6.
5 to 8.4 Hz with 3.5-mm amplitude, 8.4 to 150 Hz, acceleration of 9.8 m/s
2
,
100 min each in X, Y, and Z directions (10 sweeps of 10 min each = 100 min
total)
*1
*1. Refer to the NX-series Digital I/O Units User’s Manual (Cat. No. W521) for the vibration and shock resistance
specifications of the Relay Output Unit.
Shock resistance
Conforms to IEC 60068-2-27. 147 m/s
2
, 3 times each in X, Y, and Z direc-
tions
*1
Applicable standards
*2
*2. Refer to the OMRON website (http://www.ia.omron.com/) or consult your OMRON representative for the most
recent applicable standards for each model.
cULus: Listed UL508 and ANSI/ISA 12.12.01
EC: EN 61131-2
C-Tick or RCM, KC: KC Registration, and NK
