11 - 3
11 EtherNet/IP Coupler Unit Functions
NX-series EtherNet/IP Coupler Unit User’s Manual (W536)
11-1 Functions
11
11-1 Functions
The functions of the EtherNet/IP Coupler Unit when it is used in an EtherNet/IP Slave Terminal are
listed below.
Function Overview Reference
Setting the Slave Terminal This function is used to read and set the Slave Terminal
parameters from the Support Software. You can make
settings offline, or go online and read and set the Unit
configuration of the actual Slave Terminal.
Section 9 Setting Up
Slave Terminals
Cyclic I/O Refreshing The EtherNet/IP Coupler Unit exchanges I/O data with
the mounted NX Units.
Section 10 I/O
Refreshing
Free-Run Refreshing With this I/O refreshing method, the refresh cycle of the
NX bus and the I/O refresh cycles of the NX Units are
asynchronous.
NX Unit Mounting Settings This function is used to register NX Units that are not
connected to the actual configuration but will be added at
a later time in the Unit configuration information as
unmounted Units. If you use this function, you do not
have to modify the user program after the NX Units are
added.
11-2 NX Unit Mount-
ing Settings on page
11-4
Event Logs This function records events, such as errors and status
changes, that occur in the EtherNet/IP Slave Terminal.
11-3 Event Logs on
page 11-8
Clear All Memory This function initializes the entire EtherNet/IP Slave Ter-
minal or specified Units from the Support Software.
11-4 Clearing All
Memory on page
11-17
Restarting This function allows you to apply changes to settings with
the Support Software or through special instructions,
without cycling the Unit power supply.
11-5 Restarting on
page 11-22
Changing Event Levels This function allows you to change the level of errors that
occur in the EtherNet/IP Slave Terminal.
11-6 Changing Event
Levels on page 11-24
Resetting Errors This function allows you to use the Support Software to
reset errors that occur in the EtherNet/IP Slave Terminal.
12-4 Resetting Errors
on page 12-51
Fail-soft Operation This function allows the EtherNet/IP Coupler Unit to start
or continue I/O refreshing only with the NX Units that can
operate normally when an error occurs for the Ether-
Net/IP Slave Terminal.
11-7 Fail-soft Opera-
tion on page 11-26
Monitoring Total Power-ON
Time
Each of the EtherNet/IP Coupler Units and NX Units
records the total time that the Unit power supply is ON to
it and the total times can be displayed on the Support
Software.
11-8 Monitoring Total
Power-ON Time on
page 11-29
