Appendices
NX-series EtherNet/IP Coupler Unit User’s Manual (W536)
A-3 Examples of EtherNet/IP Slave Terminal Settings and I/O Data Control Procedure Using
Messages
A
A-3-5 Initializing the Unit Operation Settings of One NX Unit
This procedure initializes the Unit operation settings of one NX Unit in the EtherNet/IP Slave Terminal.
The unit number of the relevant NX Unit is 1.
The setting procedure is given in the following table.
You can read and write the I/O data of an EtherNet/IP Slave Terminal using explicit messages from a
device that does not support tag data link (implicit message) communications.
When you use an EtherNet/IP master that does not support explicit messages, you can use the
TCP/UDP message service to read and write the I/O data of an EtherNet/IP Slave Terminal.
The procedure is given in the following table.
A-3-5 Initializing the Unit Operation Settings of One NX Unit
Step Description
CIP objects to use
Class ID Instance ID Service code
Unit
number
1 Change the write mode of the NX
Unit to enable writing.
0x74
NX Configuration
object
0x01 0x37
Switch parameter
write mode
0x01
2 Initialize the Unit operation set-
tings of the NX Unit with unit num-
ber 1.
*1
*1. The NX-series Safety CPU Units do not support the Initialize unit operation parameter object (service code 3D
hex). An error will occur if you execute the Initialize unit operation parameter object (service code 3D hex) for
an NX-series Safety Control Unit.
0x74
NX Configuration
object
0x01 0x3D
Initialize unit opera-
tion parameter
0x01
3 Restart the NX Unit with unit num-
ber 1.
*2
*2. An error will occur if you execute the Restart NX unit object (service code 35 hex) for an NX Unit that does not
support restarting. If this error occurs, restart the entire EtherNet/IP Slave Terminal (Identity object: 01 hex,
Reset: 05 hex).
0x74
NX Configuration
object
0x01 0x35
Restart NX unit
0x01
A-3-6 Reading and Writing I/O Data for EtherNet/IP Slave Terminals
Step Description
CIP objects to use
Class ID Instance ID Service code
Unit
number
1 Write the initial values of the out-
put data to the Units in the Ether-
Net/IP Slave Terminal.
*1
0x04
Assembly object
0x94 0x10
Set_Attribute
_Single
Setting
not
required.
2 Change the Units in the Ether-
Net/IP Slave Terminal to the Oper-
ational state.
0x74
NX Configuration
object
0x01 0x39
Change NX state
0x00
3 Read the input data. 0x04
Assembly object
0x64 0x0E
Get_Attribute
_Single
Setting
not
required.
Write the output data.
*2
0x04
Assembly object
0x94 0x10
Set_Attribute
_Single
Setting
not
required.
