Appendices
A - 24
NX-series EtherNet/IP Coupler Unit User’s Manual (W536)
Values of Interface Configuration Status
Values of Configuration Capability
Values of Configuration Control
Values of Time Zone
Bit Name Value
0 to 3 Interface Configuration Status 0: IP address not set.
Includes when the IP address is not yet set during
BOOTP startup.
1: IP address set.
*1
*1. Interface Configuration Status can be read only when the IP address is set. Therefore, the value of Inter-
face Configuration Status is always 1 when read.
4 and 5 Reserved Always FALSE.
6 AcdStatus Always FALSE.
7 to 31 Reserved Always FALSE.
Bit Name Value
0 BOOTP Client
Always TRUE.
*1
*1. The value is always FALSE for NX-EIC202 version 1.0.
1 DNS Client Always FALSE.
2 DHCP Client Always FALSE.
3 DHCP-DNS Update Always FALSE.
4 Configuration Settable Always TRUE.
5 Hardware Configurable Always TRUE.
6 Interface Configuration Change Requires Reset Always TRUE.
7 ACD Capable Always FALSE.
8 to 31 Reserved Always FALSE.
Bit Name Value
0 to 3 IP address setting
method
0: Fixed IP address
1: Set from BOOTP.
2 to 15: Reserved
4 DNS Enable Always FALSE.
5 to 31 Reserved Always FALSE.
Time zone Value
(GMT -12:00) Kwajalein 0
(GMT -11:00) Midway Island 1
(GMT -10:00) USA ( Hawaii ) 2
(GMT -09:00) USA ( Alaska ) 3
(GMT -08:00) Canada, USA ( Pacific ) 4
(GMT -07:00) Canada, USA ( Mountain ) 5
(GMT -06:00) Canada, USA ( Central ) 6
(GMT -05:00) Canada, USA ( Eastern ) 7
(GMT -04:00) Canada ( Atlantic ) 8
(GMT -03:30) Canada ( Newfoundland ) 9
(GMT -03:00) Argentina 10
(GMT -02:00) Antarctica 11
(GMT -01:00) Azores 12
(GMT +00:00) England 13
To Next Page
