Omron R88D-GT series User Manual

3-88
3-4 Cable and Connector Specifications
3
Specifications
 Power Cable Connector (R88A-CNG01A)
This connector is used for power cables.
Use it when preparing a power cable yourself.
Panel Mounting Hole
 Brake Cable Connector (R88A-CNG01B)
This connector is used for brake cables.
Use it when preparing a brake cable yourself.
Panel Mounting Hole
Connector housing:
172159-1 (Tyco Electronics AMP KK)
Contact socket:
170366-1 (Tyco Electronics AMP KK)
Applicable panel thickness:
0.8 to 2.0 mm
Connector housing:
172157-1 (Tyco Electronics AMP KK)
Contact socket:
170366-1 (Tyco Electronics AMP KK)
Applicable panel thickness:
0.8 to 2.0 mm
10.351.6
2.5 5.35
10.35
(
2.28
)
3.35
14.9
23.7
±0.4
9.8
±0.15
(
4
)
11.8
±0.4
9.8
±0.15
2.84.2
2.8 4.2
(
8.8
)
10.351.6
2.5 5.35
6.15
(
2.28
)
3.35
10.7
23.7
±0.4
(
8.8
)
5.6
±0.15
9.8
±0.15
2.84.2
2.8
(
4
)
