Omron R88D-GT series User Manual

2-23
2-1 Standard Models
2
Standard Models and Dimensions
 Control Cables
 External Regeneration Resistors
 Reactors
Specifications Model
Motion Control Unit Cables for 1 axis
CS1W-MC221-V1/-MC421-V1
1 m
R88A-CPG001M1
2 m
R88A-CPG002M1
3 m
R88A-CPG003M1
5 m
R88A-CPG005M1
Motion Control Unit Cables for 2 axes
CS1W-MC221-V1/-MC421-V1
1 m
R88A-CPG001M2
2 m
R88A-CPG002M2
3 m
R88A-CPG003M2
5 m
R88A-CPG005M2
General-purpose Control Cables with Connector on One End
1 m
R88A-CPG001S
2 m
R88A-CPG002S
Connector-Terminal Block Cables
1 m
XW2Z-100J-B24
2 m
XW2Z-200J-B24
Connector Terminal Block
M3 screw type XW2B-50G4
M3.5 screw type XW2B-50G5
M3 screw type XW2D-50G6
Specifications Model
Regeneration capacity: 20 W, 50 Ω (with 150°C thermal switch) R88A-RR08050S
Regeneration capacity: 20 W, 100 Ω (with 150°C thermal switch) R88A-RR080100S
Regeneration capacity: 70 W, 47 Ω (with 150°C thermal switch) R88A-RR22047S1
Regeneration capacity: 180 W, 20 Ω (with 200°C thermal switch) R88A-RR50020S
Specifications Model
R88D-GTA5L/-GT01H 3G3AX-DL2002
R88D-GT01L/-GT02H 3G3AX-DL2004
R88D-GT02L/-GT04H 3G3AX-DL2007
R88D-GT04L/-GT08H/-GT10H 3G3AX-DL2015
R88D-GT15H 3G3AX-DL2022
R88D-GT08H/-GT10H/-GT15H 3G3AX-AL2025
R88D-GT20H/-GT30H 3G3AX-AL2055
R88D-GT50H 3G3AX-AL2110
R88D-GT75H 3G3AX-AL2220
