2-30
2-2 External and Mounting Hole Dimensions
2
Standard Models and Dimensions
 Three-phase 200 VAC: R88D-GT20H (2 kW)
Wall Mounting
External Dimensions
Mounting Hole Dimensions
UNIT No.
AC SERVO DRIVER
DATA
IM SP G
3.5
3.5
5.25.2
5.25.2
R2.6R2.6
R2.6 R2.6
5.2
dia.
5.2
dia.
20070
198
188 168
85
5017.5
5017.5
42.5
42.5
85
Four, M4
168
188
±0.5
17.5 50
