Omron R88D-GT series User Manual

2-31
2-2 External and Mounting Hole Dimensions
2
Standard Models and Dimensions
Front Panel Mounting (Using Mounting Brackets)
External Dimensions
Mounting Hole Dimensions (Reference)
UNIT No.
AC SERVO DRIVER
DATA
IM SP G
5.25.2
5.25.2
R2.6R2.6
R2.6 R2.6
5.2
dia.
5.2
dia.
20070
32
2.6
198
188 168
85
5017.5
5017.5
42.5
42.5
(89)*
Four, M4
(176)*
Square hole
188
20.5 50
6
Dimensions for front panel mounting are references values that provide leeway.
* The dimensions of
the square hole are
reference values.
