3-121
3-5 Servo Relay Units and Cable Specifications
3
Specifications
Position Control Unit Cable (XW2Z-@J-A14)
This Cable connects a Position Control Unit (CJ1W-NC113) to a Servo Relay Unit (XW2B-20J6-
1B).
Cable Models
Connection Configuration and Dimensions
Wiring
Model Length (L) Outer diameter of sheath Weight
XW2Z-050J-A14 50 cm
10.0 dia.
Approx. 0.1 kg
XW2Z-100J-A14 1 m Approx. 0.2 kg
L6
38
t = 11
500
Position Control Unit
CJ1W-NC113
Servo Relay Unit
XW2B-20J6-1B
No.
A1
A2
A8
A6
A9
A20
A11
A14
A12
A17
A19
A18
A15
A16
No.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
26
24
25
Position Control Unit Servo Relay Unit
Cable: AWG28 × 4P + AWG28 × 10C
Crimp terminal
To Next Page
