Omron R88D-GT series User Manual

2-34
2-2 External and Mounting Hole Dimensions
2
Standard Models and Dimensions
 Three-phase 200 VAC: R88D-GT75H (7.5 kW)
Front Panel Mounting (Using Mounting Brackets)
External Dimensions
Mounting Hole Dimensions (Reference)
5.2 5.2 5.2
Four, 5.2 dia.
5.2 5.2 5.2
248
339.370
45.1
(4)
(2.3)
(4)
250 220 235
85
90
9082.5
9037.5
(250)*
Six, M4
(226)*
Square hole
38.5
235
9090
4.5
* The dimensions of
the square hole are
reference values.
Dimensions for front panel mounting are references values that provide leeway.
