3-98
3-4 Cable and Connector Specifications
3
Specifications
XW2D-50G6 (M3 Screw Terminal Block)
• Dimensions
• When using crimp terminals, use crimp terminals with the following
dimensions.
• When connecting wires and crimp terminals to a terminal block, tighten
them with a tightening torque of 0.7 N·m.
Applicable Crimp Terminals Applicable Wires
Round Crimp Terminals 1.25-3
AWG22-16
(0.3 to 1.25 mm
2
)
Fork Terminals 1.25Y-3
AWG22-16
(0.3 to 1.25 mm
2
)
A1 A2 A3 A4 A5 A6 A7 A8 A9 A10
B1 B2 B3 B4 B5 B 6 B7 B8 B9
B10
6
40
7
39
17.6
7
7
M3
5.8
1.2
184
144
DIN Track lock
XG4A MIL Connector
Two, 4.5 dia.
(39.1)
(4.5)
Precautions
for Correct Use
Round Crimp Terminals
Fork Terminals
5.8 mm max.
3.2 mm
3.2-mm dia.
5.8 mm max.
