Omron R88D-GT series User Manual

2-33
2-2 External and Mounting Hole Dimensions
2
Standard Models and Dimensions
Front Panel Mounting (Using Mounting Brackets)
External Dimensions
Mounting Hole Dimensions (Reference)
GSPIM
DATA
AC SERVO DRIVER
UNIT No.
5.25.2
10015
65
5.2
R2.6
R2.6
R2.6 R2.6
5.2 dia.
5.2
dia.
5.2
20070
32.3
2.6
250 240 220
130
10015
65
(132)*
Six, M4
(228)*
Square hole
16
240
100
50
6
Dimensions for front panel mounting are references values that provide leeway.
* The dimensions of
the square hole are
reference values.
