RT
NFB
S
123
456
E
NF
Three-phase 200 to 230 VAC 50/60 Hz
L1C
L2C
L1
L2
L3
ALMCOM
/ALM37
36
CN1
X
11
10
BKIR
BKIRCOM
XB
W
V
U
B
E
M
CN2
(*3)
(*2)
CN1
CN1
B1
B2
(*4)
TB1
TB2
TB2
TB1
FN
FN
FAN Stop
( − )
(+)
XB
2MC
X
1MC
24 VDC
*1.
*2.
*3.
*4.
Regeneration
resistor
Noise filter
(*1)
(Ground to
100 Ω or less.)
(Ground to
100 Ω or less.)
User
control
device
Control Cable
24 VDC
Encoder Cable
OMNUC G-Series
AC Servomotor
Power Cable
Reactor
24 VDC
OMNUC G-Series
AC Servo Drive
Also, to ensure safety (i.e., to ensure that
the power supply can be shut OFF) for
contactor welding, we recommend using
two magnetic contactors (MC).
The model GT75H does not have a built-in
regeneration resistor. If the amount of
regeneration is large, an External
Regeneration Resistor must be connected to
B1-B2.
Recommended relay: MY Relay (24 V), by
OMRON. For example, the MY2 Relay's
rated inductive load is 2 A at 24 VDC and
applicable to all G-Series Servomotors with
brakes.
The brake is not affected by the polarity of
the power supply.
Recommended products are listed in 4-3
Wiring Conforming to EMC Directives.
1MC
PL
X
Servo error display
Main-circuit contactor (*1)
1MC
OFF
ON
X
Surge suppressor
(*1)
Main circuit power supply
To Next Page
