Omron R88D-GT series User Manual

5-6
5-3 Internally Set Speed Control
5
Operating Functions
Pn05 = 1
Pn05 = 2
*1. The mode will be analog speed control.
Input the proper current to REF.
Pn05 = 3
 Operation Example
• Internally Set Speed Control with Four Speed Changes When Pn05 = 1
No. VSEL1 VSEL2 VSEL3 Set speed
0 OFF OFF OFF Pn53
1 ON OFF OFF Pn54
2 OFF ON OFF Pn55
3 ON ON OFF Pn56
4 OFF OFF ON Pn53
5 ON OFF ON Pn54
6 OFF ON ON Pn55
7 ON ON ON Pn56
No. VSEL1 VSEL2 VSEL3 Set speed
0 OFF OFF OFF Pn53
1ON OFF OFF Pn54
2 OFF ON OFF Pn55
3ON ON OFF
*1
4OFF OFF ON Pn53
5ON OFF ON Pn54
6OFF ON ON Pn55
7ON ON ON
*1
No. VSEL1 VSEL2 VSEL3 Set speed
0 OFF OFF OFF Pn53
1 ON OFF OFF Pn54
2 OFF ON OFF Pn55
3 ON ON OFF Pn56
4 OFF OFF ON Pn74
5 ON OFF ON Pn75
6 OFF ON ON Pn76
7 ON ON ON Pn77
