6-18
6-4 Setting the Mode
6
Operation
5. Returning to Parameter Setting Mode
Key operation Display example Explanation
Press the Data key to return to Parameter Setting Mode.
Some parameters will be displayed with an “r” before the number when the
display returns to the Parameter Setting Mode Display. To enable the
settings that have been changed for these parameters, you must turn the
power supply OFF and ON after saving the parameters to the EEPROM.
When the setting for a parameter is saved, the new setting will be used for
control. Make gradual rather than large changes when changing values for
parameters that greatly affect motor operation. This is particularly true for
the speed loop gain and position loop gain.
For details on parameters, refer to Parameters Details on page 5-51.
Precautions
for Correct Use
To Next Page
