3-27
3-1 Servo Drive Specifications
OMNUC G5-Series AC Servo Drives Users Manual (Built-in MECHATROLINK-II communications type)
3
Specifications
 Serial Communications Type, Absolute Encoder Specifications (Pn323 = 2)
+5V
FG
FG
+EXS
-EXS
GND
E5V
5V
E0V
2
3
4
1
FG
GND
680Ω
680Ω
120Ω
+REQ/+SD
-REQ/+SD
Serial signal
Absolute Linear Scale
by Mitutoyo Corporation
AT573A/ST770A/ST770AL
Magnescale by Magnescale Co., Ltd
Scale Unit SR77/SR87
Shell
Shell
Servo Drive side (CN4)
