Omron SYSDRIVE 3G3JV

10-8
Parame-
ter No.
(Register
No.
(Hex))
Refer-
ence
page
Changes
during
operation
Default
setting
Unit of
setting
Setting
range
DescriptionName
n40
(0
12
8)
Multi-function
output (MA/
MB d MC
Used to select the functions of multi-function output
terminals.
0 to 7,
10 to
17
1 1 No 5-21
(0128)
p(
MB and MC
output termi-
nals)
Set
value
Function Description
17
nals)
0 Fault output ON: Fault output (with pro-
tective function working)
1 Operation in
progress
ON: Operation in progress
2 Frequency
detection
ON: Frequency detection
(with frequency reference
coinciding with output fre-
quency)
3 Idling ON: Idling (at less than
min. output frequency)
4 Frequency
detection 1
ON: Output frequency y
frequency detection level
(n58)
5 Frequency
detection 2
ON: Output frequency x
frequency detection level
(n58)
6 Overtorque
being moni-
tored (NO-
contact output)
Output if any of the follow-
ing parameter conditions
is satisfied.
n59: Overtorque detection
function selection
n60: Overtorque detection
level
7 Overture being
monitored
(NC-contact
output)
level
n61: Overtorque detection
time
NO contact: ON with
overtorque being detected
NC contact: OFF with
overtorque being detected
8
Not used ---
9
10 Alarm output ON: Alarm being detected
(Nonfatal error being de-
tected)
11 Base block in
progress
Base block in progress (in
operation with output shut-
off)
12 RUN mode ON: Local mode (with the
Digital Operator)
13 Inverter ready ON: Inverter ready to op-
erate (with no fault de-
tected)
14 Fault retry ON: Fault retry
15 UV in progress ON: Undervoltage being
monitored
16 Rotating in re-
verse direction
ON: Rotating in reverse
direction
17 Speed search
in progress
ON: Speed search in
progress
List of Parameters Chapter 10
