Parame-
ter No.
(Register
No.
(Hex))
Refer-
ence
page
Changes
during
operation
Default
setting
Unit of
setting
Setting
range
DescriptionName
12 External base
block com-
mand (NO)
ON: Output shut off (while
motor coasting to a stop
and “bb” flashing)
1 6 No 5-18
13 External base
block com-
mand (NC)
OFF: Output shut off (with
motor free running and
“bb” flashing)
14 Search com-
mand (Search-
ing starts from
maximum fre-
quency)
ON: Speed search
(Searching starts from
n09)
15 Search com-
mand (Search-
ing starts from
preset fre-
quency)
ON: Speed search
16 Acceleration/
Deceleration-
prohibit com-
mand
ON: Acceleration/Decel-
eration is on hold (running
at parameter frequency)
17 Local or re-
mote selection
ON: Local mode (operated
with the Digital Operator)
18 Communica-
tions or
remote selec-
tion
ON: RS-422/485 commu-
nications input is enabled.
OFF: The settings of n02
and n03 are enabled.
19 Emergency
stop fault (NO)
The Inverter stops accord-
ing to the setting in n04 for
interruption mode selec-
t
i
o
n wi
t
h
t
h
e
e
m
e
r
ge
n
cy
20 Emergency
stop alarm
(NO)
tion
with
the
emergency
stop input turned ON.
NO: Emergency stop with
the contact closed.
NC: Emergency stop with
th t t d
21 Emergency
stop fault (NC)
gyp
the contact opened.
Fault: Fault output is ON
and reset with RESET
input. Alarm output is ON
22 Emergency
stop alarm
(NC)
input
.
Alarm
output
is
ON
(no reset required).
“STP” is displayed (lit with
fault input ON and flashes
with alarm input ON)
34 Up or down
command
Up or down command (set
in n39 only)
By setting n39 to 34, the
set value in n38 is ignored
and the following setting
are forcibly made.
S4: Up command
S5: Down command
35 Self-diagnostic
test
ON: RS-422/485 commu-
nications self-diagnostic
test (set in n39 only)
List of Parameters Chapter 10
