Setting Measurement Items
100
ZFX-C User’s Manual
Color Pickup/Binary
This function picks up the color to be measured.
When a color camera is connected to the Controller
X MENU mode - [Setup] - [Item] - [Img Adj] - [Select camera] - [Color Pickup]
Color Pickup, p.228
When a monochrome camera is connected to the Controller
X MENU mode - [Setup] - [Item] - [Img Adj] - [Select camera] - [Binary]
Item Description
Region When an area containing a color to be measured is specified, and [AUTO] is selected, up
to four colors are automatically picked up in order of the color having the largest area.
Pickup Color If the appropriate image is not obtained by automatic color pick up, the three parameters
hue, saturation and brightness can be fine-adjusted for each candidate color.
When [Auto function] is set to [OFF], the color pick up is not updated when the automatic
setting is next executed.
To exclude a specific color from the measurement target, set [Enable/Disable] to [Disable].
Item Description
Binary level Sets the level for converting contone images made up of 256 tones captured from a cam-
era to binarized images. As white pixels are targeted in measurement, the binary level is
adjusted so that the measurement target is transformed into white pixels.
Reverse Reverses the black and white of binary images.
After the image is inverted, the area converted to white pixels is the measurement target.
To Next Page
