Specifications and External Dimensions
ZFX-C User’s Manual
7
APPENDICES
191
Controller
Specifications
ZFX-C20/C25/C10H/C15H/C10/C15
Item ZFX-C20 ZFX-C25 ZFX-C10H ZFX-C15H ZFX-C10 ZFX-C15
Number of connected cameras 2 1
Connectable camera ZFX-SR_/SC_/S/SC
Processing resolution When ZFX-SR_/SC_ is connected:464 (H) x464 (V)
When ZFX-S/SC is connected:608 (H) x464 (V)
Display LCD monitor 3.5" TFT color LCD (320 x 240 pixels)
Indicator "Measuring" indicator (color: green): RUN
Trigger indicator (color: blue): ENABLE
Judgment indicator (color: orange): OUTPUT
Error indicator (color: red): ERROR
External
I/F
Parallel interface Input 12 points (RESET, DSA, DI0 to 8, TRIG)
Output 23 points (OR, ERROR, RUN, ENABLE, GATE, STGOUT0 to 1
(*1),
DO0 to 15)
Circuit type NPN PNP NPN PNP NPN PNP
Serial interface USB2.0 1 port, FULL SPEED, MINI-B connector
RS-232C 1 port, max. 115200 bps (cannot be used simultaneously with RS-422 interface)
RS-422 1 port, max. 115200 bps
(cannot be used simultaneously with RS-232C interface)
Network
communications
Ethernet 1 port, 100BASE-TX/10BASE-T
Monitor output Analog RGB output, 1 ch (resolution VGA: 640 x 480)
Memory card I/F SD card slot 1 ch
Operation I/F Touch panel, key operation, console connection
Main
functions
Number of registered banks 32 banks
Number of setup items 128 items/1 bank 32 items/1 bank
Measurement
items
Shape inspection Pattern search, sensitive search, flexible search,
graphic search
Pattern search, sensitive
search
Size inspection Area, labeling Area
Edge inspection Position, width, count, angle Position, width, count,
angle
Brightness/color inspection
Brightness, HUE Brightness, HUE
Application-based inspection
Defects, grouping Defects
Position correction 1 model search, 2 model search, position, area,
labeling, angle
1 model search, 2 model
search, position, area,
angle
Additional
functions
Image memory function Max. 100 images (when 2 cameras are connected, 50 images/camera)
Analysis function Logging monitor -
Menu language Japanese/English (can be switched)
Ratings Power supply voltage 21.6 to 26.4 VDC (including ripple)
Current consumption 1.5 A max. 1.2 A max. 1.0 A max.
Insulation resistance Across all lead wires and Controller case: 20 MΩ (by 250 V megger)
Dielectric strength Across all lead wires and Controller case, 1000 VAC, 50/60 Hz, 1 min
Operation environment
robustness
Ambient temperature range
Operating: 0 to + 50°C, Storage: -15 to +60°C (with no icing or condensation)
Ambient humidity range Operating and storage: 35% to 85% (with no condensation)
Ambient atmosphere No corrosive gases allowed
Degree of protection IP20 (IEC60529)
Vibration resistance
(durability)
Vibration frequency: 10 to 150 Hz Single-amplitude: 0.35 mm
Acceleration: 50 m/s
2
10 times for 8 minutes in X, Y, and Z directions
Shock resistance (destructive)
150 m/s
2
3 times each in 6 directions (up/down, left/right, forward/backward)
Material Case: Polycarbonate (PC), Plate face: PMMA
To Next Page
