Monitoring the Measurement Status - RUN Mode
124
ZFX-C User’s Manual
Monitoring the Measurement Status - RUN Mode
Displaying Measurement Information
Measurement information is displayed on the LCD screen. You can switch the screen to display different
measurement information according to your specific application. To switch the screen display, either select
[Display SW] or press the F3 key.
Logging data and statistical data are erased from memory when the Controller is turned OFF.
• To reset the log without turning the Controller OFF p.121
•
To save logging data on the SD card p.150
Input the trigger using the SET and UP keys.
Previous Next Dsplay SW Capture
Individual result
Camera 0
0.Bank00
0.Pattern Search
Judge OK
Correlation 92
Position X 462
Position Y 352
Angle 15
TEA
Previous Next Dsplay sw Capture
Position
TEA
Dsplay SW Capture
All results/Region
TEA
Dsplay SW Capture
All results/Judge
0
0
1
2
3
4
5
6
7
8
9
10
11
12
1 234 5678
9
Previous Next Dsplay SW Capture
Data list(0-15)
Data0 *******.***
Data1 *******.***
Data2 *******.***
Data3 *******.***
Data4 *******.***
Data5 *******.***
Data6 *******.***
Data7 *******.***
Data8 *******.***
Data9 *******.***
Data10 *******.***
Data11 *******.***
Data12 *******.***
Data13 *******.***
Data14 *******.***
Data15 *******.***
Previous Next Dsplay SW Capture
Variables list( 0-15)
Var.0 *******.***
Var.1 *******.***
Var.2 *******.***
Var.3 *******.***
Var.4 *******.***
Var.5 *******.***
Var.6 *******.***
Var.7 *******.***
Var.8 *******.***
Var.9 *******.***
Var.10 *******.***
Var.11 *******.***
Var.12 *******.***
Var.13 *******.***
Var.14 *******.***
Var.15 *******.***
Judge0 *******.***
Judge1 *******.***
Judge2 *******.***
Judge3 *******.***
Judge4 *******.***
Judge5 *******.***
Judge6 *******.***
Judge7 *******.***
Judge8 *******.***
Judge9 *******.***
Judge10 *******.***
Judge11 *******.***
Judge12 *******.***
Judge13 *******.***
Judge14 *******.***
Judge15 *******.***
Previous Next Dsplay SW Capture
Judges list(0-15)
OK
Camera 0
0.Bank00
0.Pattern Search
Judge OK
Correlation 92
Position X 462
Position Y 352
Angle 15
X direction 20.111
Y direction 42.513
Angle 12.652
OK
353ms
353ms
OK
353ms
OK
353ms
OK
353ms
OK
353ms
OK
353ms
Statistical data/Data0
Maximum 462
Minimum 370
Average 423
Deviation 210
Count 100
NG Count 5
NG Rate 5%
Alarm Cou 20
Log SW
Display SW
Capture
Logging monitor/Data0
Data 276.000
Time 15:10:00
250
300
350
Warning
50 100 150 200
Log SW
Display SW
Capture
Individual results
All results/Region
All results/Judge
Position correction Variables list Data list
Judgments list
Results are displayed individ-
ually for each measurement
item.
The entire measurement re-
gion is displayed.
All measurement results are displayed as
a list.
Horizontal axis:Smallest digit of item No.
Vertical axis: Upper two digits of item No.
Green circle: OK
Red circle: NG
The position correction result is
displayed.
The variable results are displayed
as a list.
The data results are displayed as
a list.
The judgment results are dis-
played as a list.
Logging monitor
Measurement results are logged,
and the log is displayed as a graph.
Statistical data
The statistical values of the logged
data are displayed.
Important
Note
