ZFX-C User’s Manual
Inspection Setup and Measurement
The following describes the flow of basic setup using, as an example, inspection of whether different types of
objects are mixed in.
Setting Measurement Conditions - MENU Mode
On the ZFX, a 3-step operation completes basic inspection setup.
OK NG
TEA
Shape
Size
Edge
Bright&Color
Application
Item
Register
Position
Add func
Cameras
Pattern
Sensiti.
New
AUTO
Register model
Reference model
Search region
Move [130,140]
TEA
Region
Img Adj
Detail
Limits
Reference point
Enclose the desired measurement
area.
The optimum measurement
conditions are automatically set just
by selecting [AUTO].
Measurement conditions can also be
checked and changed.
Measurement
type group
Measurement
items
step3
Executing automatic
setting
step2
Setting measurement
regions
Measurement
items
step1
Selecting measurement
items
