Signal I/O
162
ZFX-C User’s Manual
Signal I/O
Input Signal
The following signals can be input when the ZFX-C is in the RUN mode.
Measurement Timing Input
A one-time measurement is performed if the TRIG signal is turned ON.
Command Input
Input format
Commands
Signals DI0 to DI7 can input the following commands. Allow at least 5 ms after DI0 to DI7 are determined to be
ON before turning DI8 ON.
With the model re-registration setting commands, item Nos.0 to 31 can be registered. Item No.32 onwards cannot
be registered by these commands. They can be registered by serial communication commands.
Command Description Command code Parameter (binary code)
DI7 DI6 DI5 DI4 DI3 DI2 DI1 DI0
Continuous
measurement
Measurements continue while the com-
mand is being input.
000* * * * *
Bank switching
Switches the bank to measure.
0 1 0 Bank number
Bank group
switching
Switches the bank group data.
1 1 0 Bank group number
Model
re-registration
Registers the model again based on the
last measurement image that was read.
1 0 0 Item number
Clear
measured data
Clears the following measurement results:
• Judgment results and measurement values
of measurement items
• Judgment results and measurement values
of expressions
• Logging data
• Parallel output signals
(OR, DO0 to DO15)
10100000
