Setting Measurement Items
ZFX-C User’s Manual
3
SETTING THE MEASUREMENT CONDITIONS
99
Image Adjustment
This section describes the functions for apply filters, etc. to process images captured from the camera so that
they can be easier-to-measure. Items that can be set differ according to the measurement item and type of
camera. Only available items are displayed.
Select Camera
Select camera 0 or camera 1 as the camera to be used in this measurement item.
X MENU mode - [Setup] - [Item] - [Img Adj]-[Select camera]
Color Filter
The contrast of images can be improved by passing images through color filters. This function can be set only
when a color camera is connected to the Controller. When a color filter setting is changed, a new image
processed by the color filter is displayed on the right side of the monitor. Set the color filter while monitoring the
image on screen.
AUTO Setting
Color Filter p.226
X MENU mode - [Setup] - [Item] - [Img Adj] - [Select camera] - [Color filter]
When AUTO is set for measurement items that support use of color filters, the optimum color filter is automatically
set.
Item Description
Select filter The color filter can be selected as desired. (Red, Blue, Green, Yellow, Cyan, Magenta,
Gray, Custom)
When [Custom filter] is selected, any color in the color bar can be set to the filter.
Auto function Sets whether or not to perform automatic selection of color filter processing when the
automatic setting is executed.
On: The current image is analyzed to automatically select the optimum color filter each
time that the automatic setting is executed.
Off: The currently selected color filter is fixed, and is not cleared and held even if the
automatic setting is executed.
To Next Page
