ZFX-C User’s Manual
Tools
Saving/Loading Data
You can back up setup data and measured image data on SD cards. Alternatively, these backed up data can
be loaded to the Controller.
Data that can be saved/loaded
• System data: Setup data under [System]
• Bank data/bank group data: Setup data under [Setup]
• Image data: Measurement image data saved internally on the Controller
(proprietary format: color images *.BYR, black-and-white images *.GRY)
• Logging data: Data accumulated by the logging monitor
During execution of a save or a load, do not input the RESET signal or turn the power OFF. Doing so might damage
the data, or prevent the Controller from functioning normally when it is next started up.
X MENU mode - [Tool] - [Backup]
Configuration of directory/files on SD Card
Setup Item Description
Image data Select the target data to perform save/load on.
Save: Saves the target data on the Controller to SD card.
Load: Loads target data saved on SD card to the Controller.
Logging data can only be saved.
Bank data
Bank group data
System data
Logging data
Important
Important
Image data
Directory for storing measurement image
Directory for storing bank data
Directory for storing logged results
(Any file name within 8 characters)
File name differs according to the save method.
• All Stored Image: IMAGE***.BYR (*** is a running number starting from 000.)
• Individual save: Any file name
The file extension differs according to the file type, color or black-and-white.
• Color image: .BYR
• Black-and-white image: .GRY
Bank data
Logging data
(Any file name within 8 characters)
Directory for storing bank group data
(Any file name within 8 characters)
Bank group data
Directory for storing system data
System data
(Any file name within 8 characters)
