Signal I/O
ZFX-C User’s Manual
6
PARALLEL INTERFACE
163
In the above table, a “0” indicates the signal is OFF, a “1” indicates the signal is ON. A “*” indicates that the
ZFX-C does not read the bit status, so the bit status can be either 0 or 1.
Example
Clear error
Clears the error output results.
The parallel output signal (ERROR) is
turned OFF to turn the ERROR LED OFF.
10100001
Clear parallel
terminal
Clears the parallel output signals (OR,
DO0 to DO15).
10100010
Command Description Command code Parameter (binary code)
DI7 DI6 DI5 DI4 DI3 DI2 DI1 DI0
Bank switching Switching to bank 0. 0 1 0 0 0 0 0 0
Switching to bank 1. 0 1 0 0 0 0 0 1
Switching to bank 2. 0 1 0 0 0 0 1 0
::
Switching to bank 31. 0 1 0 1 1 1 1 1
Bank group switching Switching to bank group 0. 1 1 0 0 0 0 0 0
Switching to bank group 1. 1 1 0 0 0 0 0 1
Switching to bank group 2. 1 1 0 0 0 0 1 0
::
Switching to bank group 31. 1 1 0 1 1 1 1 1
Model re-registration Re-registering the model of item 0. 1 0 0 0 0 0 0 0
Re-registering the model of item 1. 1 0 0 0 0 0 0 1
Re-registering the model of item 2. 1 0 0 0 0 0 1 0
::
Re-registering the model of item 31. 1 0 0 1 1 1 1 1
Command Description Command code Parameter (binary code)
DI7 DI6 DI5 DI4 DI3 DI2 DI1 DI0
